This is the Electric Powered, 2.4GHz Radio Controlled, 1/10 scale
Ready to Run SCX10 Ram Power Wagon Rock Crawler Truck from Axial.
Chassis: Scale steel C-channel with cross bracing for reinforcement
and assembled with hex hardware
Drive: 4 wheel shaft with WB8 wild boar driveshafts and constant
velocity joint design
Diff Locker: One-piece sintered metal construction reduces slop in
drive train by eliminating cross pin
Radio: AX-3 2-channel 2.4GHz 2-channel with high torque 132 oz/in
AS-3 digital steering servo
ESC: AE-2 LiPo compatible with forward, reverse and drag brake
function
Motor: 27T brushed motor
Pinion Gear: 48 pitch, 20 tooth
Shocks: Oil filled dual rate with realistic looking non-functional
coilover shock reservoir, plastic body
Transmission: Designed to place motor weight as low as possible
to maintain a low CG, adjustable ratio from 15:1 - 74:1, slipper
clutch allows transmission to slip in hard binds
Body: Trimmed and painted Ram Power Wagon
Wheels: Officially licensed Walker Evans molded nylon, black in
color, 12mm hex, 1.9" (48mm) diameter, 1.02" (26mm) wide
Tires: 1.9"(48mm) inner diameter Ripsaw with foam inserts
Rear Suspension: 4-link optimized to reduce axle steer and torque
twist
Bumpers: Poison Spyder Rock Brawler with functional D-Rings and
mounting holes for LED lights, swing oyt tire carrier on rear
bumper
RTR SCX10 Ram Power Wagon, 2-ch 2.4GHz radio, ESC, 27T Motor, Body
Instruction Manual, Decal Sheet
Transmitter Batteries: Four AA size
Battery: 7.2V NiMH 6-cell stick pack or 7.4V 2S LiPo pack
Battery Charger: Compatible with selected battery
Track equipment
Vehicle-
Length: 19.4" (493mm)
Width: 9" (229mm)
Height: 8.75" (222mm)
Wheelbase: 12.25" (311mm)
Ground Clearance: 2.5" (64mm)
Weight: 3.98lb (1.8kg)
Body-
Length: 19.7" (500mm)
Width: 7.9" (200mm)
Height: 4.9" (125mm)
See below for NiMH or Lipo battery and charger Options
