KIT version comes without electric parts (speed controller, motor, servo, radio system and charger/battery) for self-assembling. Differentials and shocks are built already and printed body is included.
Standard 1/10th scale setup for 540 size brushed or brushless setup.
HIGHLIGHTS:
- Racing Body Design
- Re-engineered Chassis Layout
- Including 2 Versions of Motor Transmissions (Brushed & Brushless Steel Version)
GENERAL CHASSIS FEATURES:
- 4WD
- Ball bearing transmission
- Adjustable oil shocks
- Gear differential front/rear
- Aluminum motor mount
- Complete covered transmission
- New chassis layout for better performance
- Adjustable turnbuckles
- Adjustable wishbones
- Aluminum heat sink
- Aero disc racing wheels
- Full printed body
- Sticker sheet for a unique design
- A lot tune-up parts available!
TECHNICAL SPECIFICATION:
- Measure (L/W/H): 380x255x155 mm
- Weight: 1410g
- Wheelbase: 270 mm
- Chassis clearance: 35 mm
- Tire width: 33 mm front / 42 mm rear
- Tire Ø ± 88 mm
- Shock spring force: medium / Length: 85mm f/r
- Differential oil viscosity: 1.000 front / 3.000 rear
- Shock oil viscosity: 400 f/r
- Motor transmission: Pinion 23T / Gear 64T
- Pinion module: 0.6
